SPECIFICATIONS

Base Material: FR4

Board Thickness: 1.6MM

Copper Thickness: 2OZ

High-concerned chemical: None

Min. Hole Size: 0.2MM

Min. Line Spacing: 0.127MM

Min. Line Width: 0.2MM

Number of Layers: 4-Layer

Origin: Mainland China

Silkscreen color: White

Soldermask color: Green

is_customized: Yes

Professional PCB Assembly Service | One-Stop Turnkey PCBA Manufacturer | SMT/DIP Assembly | Custom Electronics Manufacturing

Product Description

👋 Welcome to Leap Electronic – Your Trusted PCBA Partner in China

Are you looking for a reliable manufacturer to bring your electronic designs to life? We specialize in high-quality PCB Assembly (PCBA) services for prototypes and mass production. With our state-of-the-art SMT lines, we guarantee precision, speed, and competitive factory pricing.

🛠 Our Services Include:

• SMT & THT Assembly: High-speed SMT lines for 0201 components, BGA, QFN, and through-hole mounting.

• Component Sourcing: 100% original components from authorized distributors (Digi-Key, Mouser, etc.) or cost-effective local alternatives.

• Quality Testing: AOI, X-Ray (for BGA), and Full Functional Testing (FCT) before shipping.

• Flexible PCB & Rigid-PCB: Handling everything from standard FR4 to high-end Flexible Circuits (FPC).

📋 How to Get a Fast Quote? (Inquiry Guide)

To provide an accurate quote within 24 hours, please send us the following files via AliExpress Message or Email:

1. Gerber Files: Including RS-274X format or .PcbDoc.

2. BOM List (Bill of Materials): Please include part numbers, quantities, and descriptions.

3. Pick-and-Place File: Centroid file for SMT assembly.

4. Quantity: Let us know if you need 1–5 prototypes or 1000+ mass production units.

💡 Note: All your designs are strictly confidential. We are happy to sign an NDA (Non-Disclosure Agreement).

📬 Contact Us Today!

Don't place an order directly! Please contact our sales team first. Every PCBA project is unique, and we want to ensure you get the best price and technical support.

Click the "Contact Now" button or "Chat" to send your Gerber files for a free quote!

⚡ Fast Response Guarantee: We know your project is urgent. We guarantee a response to all email and WhatsApp inquiries within 2 hours during business hours and within 8 hours overnight.
